Automatic closed powder filling system Uses:

It is suitable for filling and sealing the bottom of lead-acid battery tubular grid with powder active material.

Equipment composition:

Material storage device, automatic weighing device, powder mixing machine, material conveying system, quantitative powder lowering device, automatic powder filling and sealing host, negative pressure dust removal system, control system.

Functional features:

The system has the functions of automatic weighing, automatic mixing, automatic conveying, automatic filling and so on

The powder mixed in the powder filling machine can automatically enter the conveying system, and the dust in the powder filling machine can be recovered through the dust removal system.

The equipment runs smoothly, safely and reliably, and the maintenance is simple;

Lead powder is automatically transported to the filling station, which reduces human operation and employee pollution.

Technical indicators:

Mixing capacity: 600kg/h* set

Powder filling efficiency: grid length ≤300mm, 3000 pieces/shift

300mm < grid length ≤620mm, 2000-3000 pieces/class

Powder density: 3.0-3.6g/cm³

Technical solution:

Can be designed according to customer site and production capacity.
